Pressure Tester

PF series (Rupture Tester) - PFH

PRINT

Overview    PFS    PFM    PFH

Rupture and fatigue tester PFH model can measure the limit value of rupture and fatigue of pipe, hydraulic hose and tube. It gives a test whether the test piece is destruction, fragment or leakage. Through repeated pressurizing and reducing pressure irregularly, it can measure the limit of fatigue. Ilshin Autoclave Co., Ltd has obtained ASME stamps ("U1", "U2", "S") and all the pressure vessel designs according to the regulation of ASME. Pressure vessels can be produced as the size of test piece. There are multiple options of pressure until 500kg/. For pressure's dual check, digital pressure gauge and analogue pressure gauge are attached. Multiple options can be selected by different use, please refer to Options & Accessories for more information.     Dimension Dimension 180 (W) x 1,100(D) x 850(H) ㎜ Working Pressure ~ 1,500 ㎏/㎠ Temperature 300 ℃ Flow Rate Max. 2ℓ/min Pump Type Single Acting, Single/Double Air Drive Pump (Air Port) Min. 5 ㎏/㎠ (1 /4' NPT)   Features of PFH Operation convenience • Analog pressure gauge to check pressure accurately • Simple design to make operation easily Safety • Safety valve for double control • Special manufacture is possible   Specification * PFH L Series Series Max. Pressure Temperature Pump  PFH-L500 500 ㎏/㎠ 100 ℃ Single Acting, Single/Double Air Drive  PFH-L1000 1000 ㎏/㎠ 100 ℃ Single Acting, Single/Double Air Drive  PFH-L1500 1500 ㎏/㎠ 100 ℃ Single Acting, Single/Double Air Drive   * PFH M Series Series Max. Pressure Temperature Pump  PFH-M500 500 ㎏/㎠ 200 ℃ Single Acting, Single/Double Air Drive  PFH-M1000 1000 ㎏/㎠ 200 ℃ Single Acting, Single/Double Air Drive  PFH-M1500 1500 ㎏/㎠ 200 ℃ Single Acting, Single/Double Air Drive   * PFH H Series Series Max. Pressure Temperature Pump  PFH-H500 500 ㎏/㎠ 300 ℃ Single Acting, Single/Double Air Drive  PFH-H1000 1000 ㎏/㎠ 300 ℃ Single Acting, Single/Double Air Drive  PFH-H1500 1500 ㎏/㎠ 300 ℃ Single Acting, Single/Double Air Drive   Please contact our sales team to inquire about other specification   Technical sales team : +82-42-931-6100 (Ext. 1)
