 Hot Isostatic Press - HIPL |
|
| |
|
| |
| Ilshin Autoclave's HIPL series(Max. 10ℓ) is used for laboratory and pilot study. As an inert gas is used, applying appropriate sealing type and material is very important.We installed a heater to raise a temperature (Max. 1800℃) and there are many other specifications according to size and pressure.
The vessel of HIPL is made from stainless steel for corrosion resistance and strength. HIPL series consists of high pressure pump, pressure vessel, heater and controller. We also installed pressure sensor and thermocouple for measuring temperature and pressure as well as safe vent for safety.
|
|
| |
|
| |
 Dimension |
| Working Zone |
φ60mm x 300mm I.L |
| Internal Volume |
800㎖ |
| Max. Working Pressure |
2,000㎏/㎠ |
| Max. Working Temp. |
1,000℃ |
| Material |
Alloy Steel |
| Closure Type |
Pin & Threadless Closure |
| Vacuum Pump |
Oil Rotary Pump
(Ultimate Vacuum : 700mmHg) |
| Gas Compressor |
Hydraulic Driven Type |
| Cooling System |
Water Cooling System |
|
* Surge Tank 1 set
* Kanthal Furnace And Insulator (Heating Rate : 70℃/min)
* Pressurizing Media : Argon, Nitrogen
* Control System |
| |
| Features of HIPL |
| Safety |
• Designed and manufactured according to ASME U1, U2 pressure vessel standard
• Appropriate seal type and material for high pressure
• Assure safety and accuracy by alarm system and other devices.
• Installed a valve for manual control |
| Convenience |
• Automatic valve for a cover lifting
• Digital indicator and gauge for accuracy
• Automatic system to maintain a constant pressure
• Compact workspace is compatible with various environmental conditions |
| Control system |
• Interlock setting ensure a safety
• Automatic system by PLC controlling |
| * P&ID (Piping and Instrumentation Diagram) |
 |
|
| |
|
| |
| Please contact our sales team to inquire about other specification |
| |
Technical sales team : +82-42-931-6100 (Ext. 1) |
|
|
|
