 Food Isostatic Press(High Pressure Processing) - FIP5 |
|
| |
|
| |
| Ilshin Autoclave's Food Isostatic Press(High Pressure Processing) FIP 5(~ 5ℓ) is mainly used for laboratory or research center. It is designed with various equipment size and pressure(4,000~7,000㎏/㎠) according to customer needs.
The vessel of Food Isostatic Press(High Pressure Processing) FIP5 is made from stainless steel for corrosion resistance and strength. Food Isostatic Press(High Pressure Processing) FIP5 series consists of high pressure pump, pressure vessel, heater and controller. We also installed pressure sensor and gauge for measuring pressure as well as safe vent for safety
|
|
| |
|
| |
 Dimension |
| Working Zone |
φ 50㎜ x 200㎜ I.L |
| Internal Volume |
400㎖ |
| Max. Working Pressure |
6,000㎏/㎠ |
| Max. Working Temp. |
50℃ |
| Material |
Stainless Steel |
| Closure Type |
Pin & Threadless Closure |
| High Pressure Pump Type |
Air Driven Liquid Pump |
|
* Air Cylinder (Cover on/off) 1set
* Reservoir Tank 1 EA
* Pressure Controller 1EA |
| |
| Features of HPPL |
| Safety |
• Designed and manufactured according to ASME U1, U2 pressure vessel standard
• Appropriate seal type and material for high pressure
• Assure safety and accuracy by alarm system and other devices.
• Installed a valve for manual control |
| Convenience |
• Automatic valve for a cover lifting
• Digital indicator and gauge for accuracy
• Automatic system to maintain a constant pressure
• Compact workspace is compatible with various environmental conditions |
| Control system |
• nterlock setting ensure a safety
• Automatic system by PLC controlling |
 |
|
| |
|
| |
